Gloss Dark Forged Carbon (RCF09)

by Teckwrap-CA

650.00CAD 750.00CAD

Description

With a collection of different styles, TeckWrap offers you this carbon fiber series that gives your vehicle a stylish finish with a genuine look. As a proud supplier, TeckWrap has plenty of film selections with good conformability and durability. The material is stretchable enough to wrap every edge and recessed area easily. Designed for interior and exterior applications.

Specifications

Reliable polymeric PVC for partial application. Designed for wrapping smooth surfaces or elements of medium difficulty in wrapping; spoilers, mirrors, etc.

The thickness of the film: is 0.13mm
The thickness of film with release liner: 0.29mm
Type of film: High-grade polymeric calendered vinyl film with air release channels
Colors: Black

Series: 180 series
Adhesive: Henkel solvent-based acrylic adhesive, transparent, ultra-weather-resistant, viscosity 1000~3000cps, thickness 12 μm dry
Release liner: Felix Schoeller Release Liner / 20-104-20-1,9 printed, double side PE coated Kraft. One side solventless silicone-coated, air release (ISO 9001, ISO 140001, OHSAS 18001)
Storing period: 2 years if stored in +10°С to +20°С, relative humidity 50%, in original package, away from direct sunlight, clean and dry place.
Durability/Warranty: Datasheet (Click the link)
Application: from +5°С to +30°С, usage from -30°С to +45°С
Dimensional stability: shrinkage of less than 2%
Plastification: between 28%-38%
Breaking Strength: 23.7 N/10mm (Average) Test Method: ASTM D3759/D3759M-05 6.4 N/10mm (Average) Test Method: ASTM D3330/D3330-04
Light Ageing in UV Exposure: Test Method: ASTM D4329-13 Cycle A & ISO 105-A02:1993/Cor.2:2005, Test result: 3-4 Exposure cycle: ASTM D4329-13 cycle A, Lamp type: UVA-340 8h UV at (60±2.5)℃ BPT, 0.89 W/ (m2•nm)@340nm, 4h condensation at (50±2.5)℃ BPT, Exposure duration: 44h

Post-heating: 95 Celsius

Package: Roll width is 152, length 18 m, weight 14 kg

Important

The images, colors, and finishes on screen are approximate. For the real representation of the product always check the color swatch. Rolls from the same production LOT number should be used for completing a wrap job as a slight batch to batch variation of color may occur.
